Reset panel suggestions and improvements to exisiting failure simulation

Hello! I am the one who wrote the suggestions for bird strike! Now, let’s move on to another potential additional procedures to your existing failure simulation: reset panels

For example:

According to FCOM (own copy but please consult your pilots and engineer’s for discrepancy)

Faults associated with GPS jamming includes

SURV TCAS 1(2) FAULT

SURV XPDR 1(2) FAULT

SURV GPS 1(2)FAULT

Or all faults associated with SURV

Can be eligible for an AESU 1(2) reset in the reset panel provided that

1. The ECAM/OEB procedure permits it

2. The reset is permitted in the reset table to ECAM faults such as those faults above

3. They are only permitted one at a time and cycled once. No two attempts

As failure to follow reset FCOM advice could lead to a reset in factory on ground settings such as the fmc a, b and c. The reset panels could risk erasing all data and flight plan in those systems.

What’s more, Faults such as FWS (1)2, Flaps 1(2) fault and FQMS 1(2) are eligible for reset according to the reset table.

I noticed that there is a dynamic vibration option in your failures menu thus I would like to look forward on how it behaves with a bird strike situation.

Hope it helps!

Edited 4 hours ago4 hr by schizzel
Am suprised I can’t upload images on mobile
